Sale!


MERIDA 22 eONE SIXTY 10K

$11,999.00

Our most inspiring and fun-packed e-bike ride yet, the 10K is the test and award-winning flagship of our eONE-SIXTY range. Loaded with top drawer components including XTR drivetrain, Fox Factory level suspension, carbon DT Swiss wheelset and powerful Shimano EP8 motor, the carbon/aluminium frame hosts the integrated high-capacity battery and features modern yet balanced e-enduro geometry. Best e-bike in the world? You don’t have to take our word for it – just look at the tally of test wins.

The eONE-SIXTY has seamlessly followed in the footsteps of the ‘original’ eONE-SIXTY in becoming the most decorated, tested and awarded bike in MERIDA’s history. This highly anticipated bike managed to collect a vast amount of amazing test results and wins, as well as a few more industry awards to its tally. E-Mountainbike gave it the ‘BEST IN TEST’ approval in their ‘Best of 2021’ eMTB group test, World of MTB also gave it their ‘Best of 2021’ award and FREERIDE gave the 9000 the almost perfect score of 9.5 out of ten, just to mention a few. For 2022, our carbon e-enduro bike will be equipped with the proven EP8 motor from Shimano as well as with the range extending 630 Wh internal battery. A perfectly tuned MTB geometry, paired with a stiff and lightweight carbon front triangle and tough aluminium rear, seamlessly integrated battery and a mixed wheel size combo that delivers poise and confidence on the toughest trails, the eONE-SIXTY is ready for anything you can throw at it.



https://www.merida-bikes.com/en-au/bike/2688/eone-sixty-10k



Categories: , , , , Tags: , ,


Description

01. FRAME eONE-SIXTY CFA II; MAT carbon; 150 STR; 27.5×2.8″ max. WHS; 148×12 AST; intube; max. 630 Wh
02. SIZES XS-S-M-L-XL
03. FORK FOX 38 Factory eMTB+; Air; 160 STR; Tapered; 51mm fork offset; 29×2.6″ max WHS
04. REAR SHOCK FOX Factory Float X2; platform
05. DRIVE UNIT Shimano EP8; 85Nm
06. BATTERY Shimano E8036 630Wh / Shimano E8035 504Wh for XS only
07. BATTERY CHARGER Shimano EC-E8004; 4A charging current
08. DISPLAY Shimano SC-EM800
09. MODE SWITCH Shimano SW-EM800-L
10. REAR DERAILLEUR Shimano XTR Shadow+
11. SHIFTERS Shimano XTR M9100
12. DROPPER POST LEVER EC AXS ROCKSHOX LH 1BUTTON DIS
13. BRAKE – FRONT Shimano XTR; 4 piston
14. BRAKE – REAR Shimano XTR; 4 piston
15. ROTOR – FRONT Shimano RT-MT900; 203 mm
16. ROTOR – REAR Shimano RT-EM910; 203 mm
17. CHAINRING Shimano CRE80-12-B; 34 ATC
18. CRANK Shimano FCEM900; 165 mm all sizes; hollow
19. CHAIN KMC e12T EPT
20. CASSETTE Shimano M9100; 10-51 ATC; 12 GER
21. PEDALS VP VPE-527
22. HANDLEBAR MERIDA EXPERT eTR; 780 WHB; 20 RHB
23. HANDLEBAR STEM MERIDA EXPERT eTR II; MAT aluminium; 35 DSH; 0 ASD; Supernova mount
24. STEM LENGTH 40 mm all sizes
25. SEAT POST SP REVERB AXS; 30.9 DSP; 0 SSB; XS 125 SPT – S/M 150 SPT – L/XL 170 SPT
26. SADDLE MERIDA EXPERT CC; V-mount
27. HUB – FRONT –
28. HUB – REAR –
29. AXLE – REAR MERIDA EXPERT TR; including removeable lever, 6/4mm allen key
30. RIMS DT Swiss Spline HXC1501 spline 30 boost; 110×15 WHF; 148×12 WHR; 30 IWR; Centerlock; microspline; MAT carbon; Tubeless ready (tubeless tape and valves included)
31. TYRE – FRONT Maxxis Assegai; 29×2.5 “; fold; TR EXO+ 3C MaxxGrip
32. TYRE – REAR Maxxis DHR II; 27.5×2.6 “; fold; 3C EXO+ TR
33. LIGHT FRONT LEZYNE E-BIKE POWER STVZO E115, reverse MERIDA Custom Mount
34. LIGHT REAR LEZYNE LED FEMTO USB REAR STVZO
35. OTHER MERIDA Multitool with saddlebox
36. MAX RIDER WEIGHT 140kg

Additional information

size

Large, Medium, X Large
