Description
| 01. FRAME | Double Butted Alloy E-Bike Frame, Internal Cables |
| 02. FORK | Aluminum w/ Light Mount, 12×100 TA, PS |
| 03. REAR SHOCK | – |
| 04. HEADSET | Tapered 1‑1/8″–1.5″ (ZS44/28.6 |
| 05. GRIPS | Dual Density Ergonomic, Single Lock |
| 06. HANDLE BAR | Norco Custom High Rise City |
| 07. STEM | Alloy 17 Degree Rise |
| 08. SEAT POST | TranzX YSP18PLQ Dropper, 31.6mm, 100mm travel |
| 09. SEAT POST CLAMP | Norco Alloy Nutted |
| 10. SADDLE | Norco Comfort w/Elastomers |
| 11. BRAKES | Tektro HD-M280, Hydraulic Disc, 160mm |
| 12. SHIFTER REAR | Shimano CUES SL‑U4000‑9R, 9‑speed |
| 13. REAR DERAILLEUR | Shimano CUES RD‑U4020, 9‑speed, SGS |
| 14. CASSETTE | Shimano CUES CS‑LG300‑9, 11–36T, 9‑speed |
| 15. CHAIN | KMC eGlide, 9‑speed |
| 16. CRANKSET | Shimano FC‑EM600, 38T, 165mm |
| 17. BOTTOM BRACKET | Shimano 38T chainring w/chainguard |
| 18. CHAIN TENSIONER | City Pedal, Kraton Traction Inlay |
| 19. PEDALS | Novatec sealed bearing, 15x100mm |
| 20. FRONT HUB | Alloy, 15x100mm Allen Bolt TA |
| 21. FRONT HUB SKEWER/AXLE | Novatec sealed bearing Cassette, 12x142mm |
| 22. REAR HUB | Alloy, 12x142mm, Allen Bolt TA |
| 23. REAR HUB SKEWER/AXLE | Stainless, Black, Brass Nipples |
| 24. SPOKES/NIPPLES | Alloy DW Disc, 27.5″ |
| 25. RIMS | Kenda Kwick Seven5, 27.5×2.2″, 60 TPI. Gumwall |
| 26. FRONT TYRE | Kenda Kwick Seven5, 27.5×2.2″, 60 TPI. Gumwall |
| 27. REAR TYRE | Kenda Kwick Seven5, 27.5×2.2″, 60 TPI. Gumwall |
| 28. MOTOR | Shimano DU‑EP600, 85 Nm torque, up to 250W assist |
| 29. BATTERY | Shimano BT‑EN605, 504 Wh |
| 30. KICKSTAND | Center Mount Alloy, Black, E-Bike Rate |
