Description
| 01. FRAME | 6061 Alloy, 130mm Travel |
| 02. FORK | Rock Shox Recon RL, 140mm, 44mm offset |
| 03. REMOTE | – |
| 04. REAR SHOCK | X-Fusion 02 Pro R AV, 210x50mm standard |
| 05. HEADSET | Sealed Bearing, Tapered |
| 06. HEADSET SPACER | 2x10mm & 1x5mm- Black |
| 07. GRIPS | Propalm Pro, 130mm length |
| 08. HANDLE BAR | Norco 6061 DB Alloy, 800mm, 25mm rise |
| 09. STEM | 6061 Alloy, 40mm Length, 35mm Clamp |
| 10. SEAT POST | TranzX YSI34 Dropper, 34.9mm, 150mm (S) – 170mm (M) – 200mm (L, XL, XXL) |
| 11. SEAT POST CLAMP | Norco Alloy Nutted Clamp |
| 12. DROPPER LEVER | – |
| 13. SADDLE | Norco Trail |
| 14. FRONT BRAKE | Tektro HD-M535, 4 Piston, Resin pad |
| 15. FRONT BRAKE ROTOR | TRP TR203-29, 180mm |
| 16. REAR BRAKE | Tektro HD-M535, 4 Piston, Resin pad |
| 17. REAR BRAKE ROTOR | TRP TR203-29, 180mm |
| 18. BRAKE LEVERS | Tektro HD-M535 |
| 19. SHIFTER FRONT | – |
| 20. SHIFTER REAR | Shimano CUES SL-U6000, 10sp |
| 21. FRONT DERAILLEUR | – |
| 22. REAR DERAILLEUR | Shimano CUES SL-U6000, 10sp |
| 23. CASSETTE | Shimano CUES SL-U6000, 10sp |
| 24. CHAIN | Shimano CUES |
| 25. CRANKSET | Shimano Cues FC-U6000, 30T, CL52, 170mm (S), 175mm (M-XXL) |
| 26. BOTTOM BRACKET | Shimano BB-MT501, 73mm BSA |
| 27. CHAIN TENSIONER | – |
| 28. PEDALS | VP Nylon Flat |
| 29. FRONT HUB | Formula DC-511, 15×110, 32H, 6 bolt |
| 30. FRONT HUB SKEWER | – |
| 31. REAR HUB | Formula DC-3248, 12×148, HG, 32H, 6 bolt |
| 32. REAR HUB SKEWER | – |
| 33. SPOKES/NIPPLES | Stainless, Black |
| 34. RIMS | WTB ST, 32H, F/R-29″, 30mm ID |
| 35. FRONT TIRE | Maxxis Minion DHF |
| 36. REAR TIRE | Maxxis Minion DHR |
| 37. SEALANT | – |
| 38. VALVES | – |
